AUTOMATIC 1 HEAD 4 ROLLER CAPPING MACHINE

🟥 Description:

The main structure is made of durable 304 stainless steel. The machine is controlled by a touch screen, parameters can be set on the touch screen very easily. It is very flexible for different sizes of round bottles, square bottles, and flat bottles by adjustment. Capping time can be set to fit different caps and different levels of tightness. It is very easy to existing line upgrade.

🟥 Features:

🔸 Controlled by PLC & touch screen.

🔸Adjustable for different sizes and shapes of caps and bottles

🔸Bottle belt holding system.

🔸 GMP standard stainless steel.

Technical Specifications

Model FTM-CM4R-1F
Bottle height 50-350mm
Bottle caps diameter  20-50mm
Working speed  20-60 bottles/minute
Working voltage  AC220V 50-60Hz
Power 1Kw
Compressed Air pressure 0.4-0MPa
Capping torsion  4-9kgf/cm
