🟥 Work flow:

1. Connect the power supply, and the power indicator, connect the air supply.
2. Press the start button, the machine starts, and the belts drive.
3. Manual adjustment for different cardboard width and height.
4. Without folding the carton flaps, push the carton box to the belts area, the belts will drive the carton box forward.
5. The machine automatically fold carton top flaps, the taping head will seal the cardboard box, the finished cardboard box sent out via the belts.

🟥 Features:

• Pneumatic cylinder to fold the upper part of the body.
• Two motorized side drive belts
• Equipped with two free roller conveyors upstream and downstream.
• Two powerful 220v motors in the lower part of the machine.
• Easy adjustment in height and width of cardboard.
• Roller table made of stainless steel mounted on adjustable feet.
• Adjustable tape tension.
• Energy saving with delayed stopping of the drive at the end of wrapping.
• Side guides symmetrical adjustable manually.
• 2 wrapping heads lower and upper adhesive width 48 – 72 mm.
