AUTOMATIC MONO CARTON PACKING MACHINE

🟥 Description:

This machine is specially designed for the direct packing of powdery materials. It integrates automatic lifting, weighing and measuring, automatic box opening, filling and sealing. It is controlled by motion controller and servo driven for precise positioning.

🟥 Features:

  •  Controlled by motion controller.
  •  Precise positioning by servo drive.

Technical Specifications

Model FTM-250A FTM-250C FTM-250W
Measuring Device Servo Auger Volumetric cups Weigh filler
Filling Range Upto 300gm Upto 900gm Upto 2500gm
Speed 20-40 Cartons/min 15-30 Cartons/min 5-20 Cartons/min
Voltage 380V 3Phase 50/60Hz
Power 5.5 Kw 5 Kw 5.2 Kw
Air required 8CFM @ 6bar pressure
