AUTOMATIC PISTON TYPE LIQUID/PASTE FILLING MACHINE

🟥 Description:

Our Automatic Piston Filling Machine is compact and highly efficient machine with elegant look. This machine is suitable for filling of all kinds of liquid or paste such as chilly sauce, tomato sauce, honey, ghee, juices, oil etc. It can be used for glass bottles, metal cans, aluminum cans, easy-pull cans, PET cans, shaped cans and other bottle and jar containers.

🟥 Features:

  •  High accuracy.
  •  Anti-dripping long nozzles.
  •  Touch screen control.
  •  No Bottle – No Filling System.

Technical Specifications

Model FTM-APF-2XS FTM-APF-2X FTM-APF-4XS FTM-APF-4X FTM-APF-6XS FTM-APF-6X FTM-APF-8XS FTM-APF-8X
Volume Adjustment Touchscreen Manual Touchscreen Manual Touchscreen Manual Touchscreen Manual
No of Filling Nozzles 2 Nozzles 4 Nozzles 6 Nozzles 8 Nozzles
Output Upto 30BPM Upto 40 BPM Upto 60 BPM Upto 80 BPM
Filling range 10-100ml / 50-250ml / 100-1000ml / 250-2500ml / 500-5000ml
Compressed Air required 8CFM @ 6bar pressure
Hopper Volume 70Ltr 100Ltr 150Ltr 150Ltr
Voltage 220V 1Phase 50/60Hz
