🟥Description:
Sleeve Sealing Machine is Designed for Producing Transit Packs in PE Shrink Film. Two Rolls of Flat PE are Sealed Producing a “Curtain” of Film. The Pack Travels into this “Curtain” of Film Producing a Sleeve Around the Pack which Shrinks Tightly in the Shrink Tunnel.
| Model | FTM-6030A | FTM-6040 |
| Machine Dimensions | 1206 X 1274 X 2051mm | 2404 X 980 X 1690mm |
| Tunnel Chamber Size | / | 1500 X 600 X 400mm |
| Max Packing Size | 500 X 300 X 300mm | 1300 X 400 X 300mm |
| Sealing Blade Size (L) | 700mm | / |
| Temperature Range | 0 – 200℃ | 0 – 400℃ |
| Working Table Height | 850 ± 50mm | 850 ± 50mm |
| Capacity | 5 – 8pcs/m | 15 – 20pcs/m |
| Power | 1.3kw | 20kw |
| Power Source | 3Phase 380V 50Hz | 3Phase 380V 50Hz |
| Air Source | 6 – 8 kg/cm² | / |
| Applicable Film | PE | PE |
