EXTERNAL VACUUM PACKING MACHINE

🟥 Description:

Heavy duty external vacuum packing machine is one of the most excellent external pumping vacuum packer. It is specially designed for big package.



🟥  Features:

  •  Digital Controller.

Microcomputer program control system, waterproof panel and LCD display. Parameter setting is simple and process control is accurate. 8 kinds of packing modes can be preset.

Mode 1: Sealing only

Mode 2: Vacuum – Sealing

Mode 3: Gas filling – Sealing

Mode 4: Vacuum – Gas Filling – Sealing

Mode 5: Gas Filling – Vacuum – Sealing

Mode 6: Vacuum – Gas Filling – Vacuum – Sealing

Mode 7: Gas Filling – Vacuum – Gas Filling – Sealing

Mode 8: Vacuum – Gas Filling – Vacuum – Gas Filling – Sealing

  •  Long nozzle. The length of the nozzle is 0 – 200 mm (0 – 8″) adjustable, only need 3 – 8 seconds to remove all the air out of the package. The nozzle can also fill the bag with nitrogen or other inert gas.
  •  Special sealing unit. Al-Mg alloy support. Silicon sealing unit which is high temperature resistant, and extra 1 strip at each side of the sealing unit. Thus to ensure nice seal on bags.
  •  Adjust machine head. The angle of machine head is 0 – 90° adjustable and very easy to adjust.
  •  It suits for almost all the product, except powder, fluid, fragile product etc.

Technical Specifications

Model  FTM-800EV
Seal Bar Length  800mm
Seal Width  8mm
Number of Seal Bars  1
Number of Nozzles  1
Vacuum Rate  700 CBF/h (20 CBM/h)
Packing Capacity  10 – 20 seconds of one cycle
Adjustable Packaging Height  690 – 1490mm
Voltage  220V 1Phase 50Hz
Sealing Power  600W
Compressed Air Requirement  0.5MPa
