🟥 Description:

FTM-BC3 Pneumatic bottle washing and drying system described uses a pressure-activated diaphragm pump to clean bottles and a separate compressed air system to dry them.

🟥 Washing operation

• Preparation: The diaphragm pump is connected to a tank containing water and detergent. The system uses compressed air.
• Activation: The user places 2 bottles upside down over the nozzles and applies foot switch.
• Washing: The pressure activation diverts compressed air to the diaphragm pump, causing the pump to push the water and detergent mixture from the tank into the nozzle and spray it forcefully inside the bottle.

🟥 Drying operation

• Preparation: After washing, the user moves the bottle to a separate set of nozzles connected to a supply of pure compressed air.
• Activation: The user repeats the same process: placing the bottle upside down over a new nozzle and press foot switch.
• Drying: This action activates a valve that directs compressed air into the bottle, blowing out any remaining water droplets.

🟥 Advantages

• No electricity needed: The system operates entirely on compressed air, making it safe to use in damp environments.
• Manual control: The operator has complete control over the cleaning and drying process for each individual station.
