SHRINK TUNNEL (LX SERIES)

🟥 Features:

  • Blowing  system installed below with the whole shrinking process visible through the observation window.
  • Conveyor speed and air volume controlled by inverters, wind whole opening and blowing direction adjustable.
  • Chamber can be opened, easy for cleaning and maintenance.
Enquire Now

Technical Specifications

Model FTM-5030T FTM-5030LX FTM-6530LX FTM-8030LX
Machine Dimension 1800x990x1300mm 1872 x 1035 x 1305mm 1872 x 1185 x 1305mm 1872 x 1335 x 1305mm
Tunnel Chamber Size 1500x500x300 1500 x 500 x 300mm 1500 x 650 x 300mm 1500 x 800 x 300mm
Capacity 0~20 m/min 0~20 m/min 0~20 m/min 0~20 m/min
Power 13Kw 16Kw 18Kw 20Kw
Power supply 3Phase 380V 50Hz 3Phase 380V 50Hz 3Phase 380V 50Hz 3Phase 380V 50Hz
Applicable Film POF/PE POF/PE POF/PE POF/PE
