SHRINK TUNNEL (POF)

🟥 Application:

Suitable for the packing demands of the mass production in industries suck like electronics, hardware, plastic, software, food, printing, pharmaceuticals, floors and other construction materials.

🟥 Features:

  • Stainless heating tubes and  strong blowing motor ensure high heating efficiency, large air volume and uniform air circulation.
  • Solid metal rods wrapped by heat-resistance silicone tubes make the Conveyor rollers strong and resilient.

Technical Specifications

Model FTM-4525 FTM-5030
Machine Dimension 1300 x 700 x 1465mm 1662 x 806 x 1564mm
Tunnel Chamber Size 1000 x 450 x 250mm 1300 x 500 x 300mm
Capacity 0~15 m/min 0~15 m/min
Power 9Kw 12Kw
Power supply 3Phase 380V 50Hz 3Phase 380V 50Hz
Applicable Film POF POF
